Versandbedingungen
Verpackungsdetails Kartons , Paletten oder Sperrholzkisten
Versandbedingungen: EXW, FOB, CIF, DDU, DDP
Versandart: Auf dem Luftweg, auf dem Seeweg, über Land
Nicht nur CALB L173F324Ais a large-capacity prismaticLiFePO₄ (LFP) Batteriefrom CALB’s L173 series, designed for high-reliability energy storage and heavy-duty applications. With its high capacity, Langkreislebensdauer, and excellent safety performance, this cell is widely used in residential, kommerziell & industriell (C.&ICH) Energiespeichersysteme, UPS solutions, and other long-life power applications.
Built on CALB’s proven lithium iron phosphate chemistry, the L173 series delivers stable performance, high thermal stability, and outstanding durability, making it a preferred choice for large-scale battery modules and battery packs.
Key Electrical Specifications
Nein.
Artikel
Parameter
Bemerkungen
1
Nennleistung
324 Ah
Standardentladung
2
Nennspannung
3.21 V.
Standardentladung
3
Nennenergie
1043.3 Wh
Standardentladung
4
Zellengewicht
5.56 ± 0.15 kg
—
5
Massenenergiedichte
187 Wh/kg
Standardentladung
6
Zellvolumen
2.55 L (ohne Terminal)
—
7
Volumenenergiedichte
409 Wh/L
Standardentladung
8
AC Internal Resistance (ACR)
0.2 – 0.25 mΩ
29% SOC, Raumtemperatur, AC Impedance, 1000 Hertz
9
Ladetemperatur
-5 ~ 65 °C
—
10
Schnelle Ladezeit
≤ 36 Mindest
25°C, 20%–80% SOC
11
Spannungsbereich
2.5 ~ 3.65 V.
0°C < T ≤ 65°C
2.0 ~ 3.65 V.
-30°C ≤ T ≤ 0°C
12
Entladungstemperatur
-30 ~ 65 °C
—
13
Lagertemperatur
-40 ~ 65 °C
—
Schlüsselvorteile
Hohe Kapazität & Energiedichte
With a capacity exceeding 300Ah, the L173F324A significantly reduces the number of cells required per system, simplifying battery pack design and improving overall system efficiency.
Excellent Safety Performance
LiFePO₄ chemistry provides superior thermal and chemical stability compared with high-nickel lithium systems, greatly reducing the risk of thermal runaway and ensuring safe operation in demanding environments.
Why Choose CALB L173F324A
The CALB L173F324A combineshohe Kapazität, Langkreislebensdauer, and proven safety, making it an excellent choice for modern energy storage systems that demand reliability, Skalierbarkeit, and long-term value.
Individuelle Preise für Großprojekte und Großhandelsanforderungen sind verfügbar.
