The home energy storage battery pack has a built-in BMS, can be adapted to a wide range of brands of inverters and supports a variety of communication methods. Certification with msds, un38.3, ce, etc.It has been exported in large quantities to countries in Africa, Europe and South East Asia. As a high volume manufacturer, we will give you the most competitive prices with guaranteed quality.For more real pictures and videos of our products (including production, delivery, testing, certificates, data and cooperation with customers, etc.) please contact us. Let our batteries power your business!
enquiry
Battery pack datesheet
| Battery Cell | Capacity | 100Ah |
| Nominal Voltage | 3.2 V | |
| Dimension | 49.9x 160x 118.5mm | |
| Weight | 2kg | |
|
Battery parameters | Combination Method | 16S1P |
| Capacity | Nominal Capacity: 100Ah | |
| Voltage | Nominal Voltage: 51.2V Cut-off Voltage: 44.8V~ 57.6V | |
| Charge | Standard Charge: 0.5C(50A) Quick Charge: 1C(100A) | |
| Discharge | Discharge Current: 100A | |
| Weight | 43± 1Kg | |
| (L×W × H) Dimension | 566mm*362mm*135mm | |
| Operating Temperature | Charge: 0℃ ~45℃； Discharge: -20℃ ~60℃； | |
| Parallel options | Protection function | Single over-voltage/under-voltage, charging/discharging over-current, short circuit, temperature |
| Cycle life | ＞6000 times | |
| Protection level | IP20 | |
| Communication type | CAN, RS485, RS232 | |
| Parallel Qnt | 16 groups (series connection not supported) |
Inverter matching list
| NO. | Inverter | Protocol | Communication Type |
| 1 | Goodwe | Goodwe Communication Protocol-v 1.5 | CAN |
| 2 | PYLONTECH | CAN-Bus-protocol-PYLON-v 1.3 | CAN |
| 3 | Growatt | Growatt protocol (RS485) | RS485 |
| Growatt BMS CAN-Bus-protocol low voltage-V1.05 –English version | CAN | ||
| 4 | Victron | Voltronic Inverter and BMS 485Communication protocol | RS485 |
| 5 | LXP | Luxpowertek Battery CAN Protocol | CAN |
| 6 | Sofar | CAN Note rev5 | CAN |
| 7 | Deye | Same as PYLONTECH | CAN |
| 8 | FOX ESS | Same as PYLONTECH | CAN |
| 9 | Sermatec | Same as PYLONTECH | CAN |
Individual pricing for large scale projects and wholesale demands is available.
